APC Easy UPS BV 1000VA 600W Universal 230V – BV1000I-MSX

APC BV1000I-MSX is a 1000VA / 600W line-interactive UPS designed to provide battery backup and voltage regulation for computers, networking equipment, POS systems, and office electronics. It features AVR, four universal battery-backup outlets, LED status indication, surge protection, and cold-start capability. With a compact floor/wall-mount design, it is suitable for home offices, retail counters, workstations, and small IT equipment.

Specifications of APC BV1000I-MSX

Power Budget

1000VA / 600W

• 1000VA = UPS apparent power rating
• 600W = maximum real power the UPS can supply
• The combined power consumption of all connected equipment must remain within 600W

Recomended : connect a PC consuming 250W, monitor 50W, router 15W and another device consuming 100W

APC BV1000I-MSX Connectivity

AC Input

• 1 × AC input
• BS1363A British input connection
• 230V AC
• 1.5m integrated input power cable

AC Output

• 4 × Universal outlets
• All 4 outlets provide battery backup

The four outlets mean you can connect up to four compatible devices physically, but the combined load must remain within the 600W maximum.

What’s in the Box

• 1 × APC Easy UPS BV1000I-MSX
• 1 × 1.5m AC Input Power Cable
• 1 × User Manual

FAQ

What is the maximum power capacity of the APC BV1000I-MSX?
It supports 1000VA / 600W. The maximum real power load is 600W.

How many devices can be connected?
It has 4 universal battery-backup outlets. The total connected load must not exceed 600W.

What type of power cable is included?
The UPS includes one 1.5m AC input power cable with a BS1363A British input connection.

Does the BV1000I-MSX have AVR?
Yes. Automatic Voltage Regulation helps correct voltage fluctuations without unnecessarily switching to battery power.

Is this a pure sine-wave UPS?
No. It provides a stepped approximation to a sinewave output.

Can it be rack-mounted?
No. It is not rack-mountable. It has a compact floor/wall-mount design.
