Haysenser SATA 15-Pin to 6-Pin PCI-Express PCIe Power Adapter Cable – 20cm Best Long-Lasting Cable
Haysenser SATA 15-Pin to 6-Pin PCIe Power Adapter Cable connects a 15-pin SATA power cable to a 6-pin PCIe power input, with a 20cm 18AWG wire for reliable performance in compatible PC and graphics card setups.
Haysenser SATA 15-Pin to 6-Pin PCIe Power Adapter Cable – 20cm
Haysenser SATA 15-Pin to 6-Pin PCIe Power Adapter Cable is designed to connect a 15-pin SATA power connection to a compatible 6-pin PCIe power input on supported graphics cards and computer hardware. The 20cm cable uses 18AWG wire and is marked AWM 1007, VW-1, 80°C, 300V and FT1. Its compact design is suitable for compatible PC builds and internal hardware configurations.
Specifications of Haysenser SATA 15-Pin to 6-Pin PCIe Power Adapter Cable
Specification |
Details |
|---|---|
Brand |
Haysenser |
Product Type |
SATA to PCIe Power Adapter Cable |
Connector 1 |
SATA 15-Pin Power |
Connector 2 |
6-Pin PCIe Power |
Cable Length |
20cm |
Wire Gauge |
18AWG |
Wire Specification |
AWM 1007 |
Voltage Rating |
300V |
Temperature Rating |
80°C |
Flame Rating |
VW-1 / FT1 |
Application |
Compatible PC and graphics card power connections |
Cable Color |
Black |
Connectivity
Connectors
- 1 × SATA 15-Pin Power Connector
- 1 × 6-Pin PCIe Power Connector
The adapter is intended to provide a power connection between a compatible 15-pin SATA power output and a 6-pin PCIe power input.
What’s in the Box
- 1 × Haysenser SATA 15-Pin to 6-Pin PCIe Power Adapter Cable – 20cm
FAQ
What is the Haysenser SATA 15-Pin to 6-Pin cable used for?
It connects a compatible 15-pin SATA power connection to a 6-pin PCIe power input.
What is the cable length?
The cable is 20cm long.
What wire gauge does the cable use?
It uses 18AWG wire.
What markings are printed on the cable?
The wire is marked AWM 1007, VW-1, 80°C, 300V, 18AWG and FT1.
Is this cable suitable for every graphics card?
No. It should only be used where the device and power supply configuration specifically support a SATA-to-6-pin PCIe power connection.
