Ruijie RG-RAP2266 WiFi 6 AX3000 Best Ceiling Access Point | 2976Mbps Dual Band Gigabit PoE Wireless AP
Ruijie RG-RAP2266 WiFi 6 AX3000 ceiling access point delivers up to 2976Mbps dual-band wireless speed with Gigabit Ethernet, PoE support, MU-MIMO, Reyee Mesh and cloud management for reliable business WiFi networks.
Description
Ruijie RG-RAP2266 WiFi 6 AX3000 Ceiling Access Point | 2976Mbps Dual Band Gigabit PoE Wireless AP
Ruijie Reyee RG-RAP2266 is a WiFi 6 AX3000 ceiling-mounted access point designed for offices, hotels, schools and commercial environments. It delivers up to 2976Mbps combined wireless speed with 2401Mbps on 5GHz and 573Mbps on 2.4GHz, featuring Gigabit Ethernet, PoE support, MU-MIMO, Reyee Mesh and cloud management for reliable business WiFi deployment.
Key Features for Ruijie RG-RAP2266
- WiFi 6 AX3000 Technology for faster speed and better network efficiency
- Dual Band Wireless Performance
- 5GHz: Up to 2401Mbps
- 2.4GHz: Up to 573Mbps
- Total Wireless Speed: Up to 2976Mbps
- 1 × Gigabit Ethernet Port for high-speed wired uplink
- PoE Supported for easy installation without separate power cable
- Ceiling Mount Design suitable for offices, hotels and commercial spaces
- MU-MIMO Technology allows multiple users to connect simultaneously
- Supports up to 512 connected clients
- Recommended for 50–100+ active users depending on usage
- Reyee Mesh Support for expanding wireless coverage
- Cloud Management Support for remote monitoring and control
- Smart Roaming Support for smooth movement between access points
- Plug & Play Setup with easy installation and configuration
Specifications
Specification |
Details |
|---|---|
Brand |
Ruijie Reyee |
Model |
RG-RAP2266 |
Product Type |
Indoor Ceiling Access Point |
WiFi Standard |
WiFi 6 (802.11ax) |
WiFi Class |
AX3000 |
Maximum Wireless Speed |
Up to 2976Mbps |
5GHz Wireless Speed |
Up to 2401Mbps |
2.4GHz Wireless Speed |
Up to 573Mbps |
Frequency Band |
Dual Band (2.4GHz + 5GHz) |
Antenna Type |
Built-in Omnidirectional Antenna |
MIMO Technology |
2×2 MU-MIMO |
Wireless Capacity |
Up to 512 Clients |
Recommended Active Users |
50–100+ Users |
LAN Port |
1 × Gigabit Ethernet Port |
Ethernet Speed |
10/100/1000Mbps |
PoE Support |
Yes (802.3at PoE+) |
Power Supply |
PoE or 12V/2A DC Adapter |
Maximum Power Consumption |
18W |
Installation Type |
Ceiling / Wall Mount |
Plug & Play |
Yes |
Mesh Support |
Yes (Reyee Mesh) |
Cloud Management |
Yes |
Smart Roaming |
Supported |
Dimensions |
220 × 220 × 52.6mm |
Weight |
Approx. 0.95 kg |
Operating Temperature |
0°C to 40°C |
Colour |
White |
Speed & User Performance
Usage Type |
Approximate Users |
|---|---|
Web browsing / Email |
100+ users |
Office applications |
50–100 users |
Video meetings / Streaming |
30–60 users |
Heavy bandwidth usage |
Depends on network load |
(Actual speed depends on internet connection, device capability, distance and interference.)
In The Box
- Ruijie Reyee RG-RAP2266 Access Point
- Ceiling mounting bracket
- Installation accessories
- Quick installation guide
(Power adapter availability depends on package)
